Product Specification
Length x width x height | 6850×2550×3910mm/7350×2550×3910mm |
Wheelbase | 3300+1350mm/3800+1350/4000+1350 mm |
Front/ Rear wheel distance | 2030/1860/1860mm |
Front/ Rear suspension | 1430/875 mm |
Total weight/Gross combination weight | 70000 kg |
Curb weight / Gross vehicle weight | 9000 kg |
Seat | 2 |
Max.speed | ≥109km/h |
Max.gradient | ≥30% |
Mini.turning radius | ≤17 m |
Mini.ground clearance | 270 mm |
Approaching/leaving angle | 15°/41° |
Engine Specification | |
Model | Weichai，Cummins |
Rate power | 430hp-550hp |
Emission standard | Euro III,IV,V,VI |
Displacement | 11.8 Litre |
Chassis Specification | |
Gearbox | FAST/ZFGearbox |
Clutch | Eaton Brand |
Front Solo axle | 6.5T Meritor axle |
Rear Tandem axle | 13T Meritor axle, disc plate ratio：4.11 |
Brake system | Compressed air disc brake/Spring energy storage breathe brake/ engine brake |
Driving axle | 2 |
Driving model | 6x4 |
Tyre | 12R22.5 18PR,11.00R20 18PR,12.00R20 16PR,315/80R22.5 18PR/315/80R22.5 16PR,295/80R22.5 18PR |
Fuel tank | 400-1000L Aluminium alloy |
Others | ABS.GPS,Rearview radar, rim cover, Key start |
Cab Specification | |
Cab | High top(Volvo Design) |
Air conditioner | Cool/Heat(Auto, independent air conditioner with warm and cold wind) |
Sleep | 2 wide sleppers |
Body colour | optional |
Others | four-direction adjust steering wheel, Rear air suspension，Air deflector,8*Continental air bag suspension, Wabco valves |
Product Properties
1.Cab: the appearance of streamlined design, V-shaped front face shape, three ladder mask, car-level paint, noble and elegant, filling high-end style.
The overall style of the cab
The overall style is simple, elegant, gives the soul of calm, to create a sense of comfort, center console and the floor with dark, different color contrast enhanced cab spacious visual atmosphere.
Airbag seats
The use of headrest integrated air damping seat, according to their own needs to adjust, greatly reduce the driver's long-distance driving fatigue.
Automatic air conditioner
The temperature and humidity can adjust automatically according to the setting.
Sleeper widened
The sleeper is widened and added protective fence, reading lamp, which is convenient for rest and reading, embodying the human—oriented designing idea.
Automatic cruise
Reduce the unnecessary speed changes, while saving energy consumption at the same time effectively reduce the degree of fatigue of occupants.
Top sunroof
Speed up the air flow inside the cab and improve the car environment, conducive (which is beneficial) to physical and mental health.
Control console
Using S-shaped surface, to create a sense of overhead. Semi-package instrument design makes the driver more convenient control, surrounded by a sense of stronger, more sense of security; great sense of science and technology touch large screen, key control clear, clear, the driver can easily operate the functions of the vehicle.
LCD instrumentation
The newly increased function of instantaneous fuel display, as a result the drivers can casually get aware of the fuel-consumption variation and thus better control the fuel-consumption while driving.
2.Cummins Engine: 2000bar Ultra High Jet Pressure Enables the engine to better atomize the fuel, making the combustion more fully economical. The whole weight of the module design, parts reduction of 30%, weight loss of about 200kg, intelligent speed control patented technology according to the vehicle operating environment, intelligent control of engine speed, to achieve the best fuel economy.
3.Aluminum gearbox: multi-gear large center distance from the aluminum gearbox, light weight, good heat, long life, low maintenance costs, high comprehensive income.
Maintenance-free rear axle: reliable quality, easy maintenance, good heat dissipation, long life, integrated lightweight design, light weight, low failure rate, high transmission efficiency.
4.Frame: the use of simulation simulation and electrical measurement technology, the use of high-strength steel, a stamping machine frame, frame strength increased by 50%, anti-rollover ability.
5.Aluminum alloy fuel tank: aluminum alloy large capacity fuel tank, increase mileage, reduce the number of refueling; aluminum alloy material, reduce weight, more beautiful.
Four-point suspension: air bag suspension, improve vehicle comfort, in the event of an impact, the cab as a whole move back 20 cm, fully protect the driver safety.
Application
Mainly for daily industrial products, express delivery, cold chain, light throw transport industry in the long-distance logistics and transport.
