Product Specification
Length x width x height | 10480x2490x3900mm |
Wheelbase | 1800+3200+1350mm |
Front/ Rear wheel distance | 2037/2037mm；1860/1860mm |
Front/ Rear suspension | 1430/2700 |
Total weight/Gross combination weight | 30000 kg |
Curb weight / Gross vehicle weight | 15950 kg |
Max.speed | 95km/h |
Engine Specification | |
Model | Weichai |
Rate power | 340hp |
Emission standard | Euro III |
Displacement | 9.726 Litre |
Chassis Specification | |
Gearbox | FAST 12J |
Front Solo axle | 7.5T |
Rear Tandem axle | 13T |
Driving model | 8x4 |
Tyre | 12.00R20 |
Truck Loading | |
Capacity | 6.9m³ |
Others | Heat/A.C. |
Product Properties
1.Stirring device is mainly composed of mixing drum and auxiliary support components. Mixing drum of concrete loaded containers, rotates the concrete along the blade spiral direction, constantly in the process of ascension and turning by mixing and stirring. In the process of feeding and transport, mixing barrel forward, concrete, moving along the blade into the discharge, the mixing tube inversion, the concrete to discharge along the blade.
2.Blade is the main components in the mixing plant, serious wear and tear or damage can lead to concrete mixing unevenly. In addition, the Angle of the blade if the design is not reasonable, still can make concrete segregation.
3.Cleaning system is the main purpose of cleaning the mixing barrel, is also sometimes used to transport on the way to dry mixing drum. Cleaning system and cooling effect to the hydraulic system. Totally enclosed device adopts rotary sealing technology, sealed the mixers in and out of the mouth, to solve the traditional mixing heavy evaporation, stratification of mortar,concrete material spilled, the series of problems such as driving safety.
Application
DAYUN 8*4 concrete mixer truck mixer concrete
